// Mortar Spraying Machine B4

8 - HOURS DAILY PRODUCTION

BASE MORTAR:
12,000 – 17,000 square meters

MORTAR:
800 – 1,300 square meters

MORTAR FINISH (marble – line):
1,200 – 1,500 square meters

ROUGH FINISH:
1,200 – 3,200 square meters

FLOOR SCREED:

500 square meters ( with 8mm thickness)

CEMENT INJECTIONS


Technical data EKTOXEFTIS Model: B4
Delivery rate (l / min) 25 – 115
Delivery pressure (bar) 40
Delivery distance (meters) Up to 300m horizontally and 100m high
Air compressor 2-cylinder compressor, 3.5 bar, 300 l/min
Drive motor Diesel engine 22 HP or Electric motor 10 or 15 HP
Outside dimensions
Length X Width X Height (mm)
2200 x 1640 x 1760
Max. grain size (mm) 8
Discharge connection M50
Weight (Kg) 1000
