Technical Spec
// Mortar Spraying Machine B2

8 - HOURS DAILY PRODUCTION

BASE MORTAR:
10,000 – 15,000 square meters

MORTAR:
800 – 1,100 square meters

MORTAR FINISH (marble – line):
1,000 – 1,300 square meters

ROUGH FINISH:
1,200 – 3,200 square meters

ROUGH FINISH:
1,000 – 3,000 square meters

CEMENT INJECTIONS

Technical data EKTOXEFTIS Model: B2
Delivery rate (l / min) 15 – 65
Delivery pressure (bar) 40
Delivery distance (meters) Up to 300m horizontally and 100m high
Air compressor 2-cylinder compressor, 3.5 bar, 300 l/min
Drive motor Diesel engine 16 or 22 HP or Electric motor 10 HP
Outside dimensions
Length X Width X Height (mm)		 2200 x 1640 x 1760
Max. grain size (mm) 8
Discharge connection M50
Weight (Kg) 1000
